LBL-3650 ∅36mm DC Brushless Motor
36mm diameter micro DC brushless motor, could with 36mm reduction gearbox, specific parameters customized by request.
Additional information
| Model | LBL-3650 |
|---|---|
| Type | DC Brushless Motor |
| Body Size | Φ36*50mm |
| Shaft Size | Φ4.0mm diameter, Length customized by request |
| Weight | 180g (Approx) |
| Voltage | 6v-26v |
| Output Power | ≤35W |
Product Details:
36mm Diameter Micro DC Brushless Motor
+ Brand: Linkto Motor
| Model: | LBL-3650 | Type: | DC Brushless Motor |
| Voltage: | 6v-26v | Speed: | 1000rpm-16000rpm |
| Continuous Current: | ≤6500mA | Stall Torque: | ≤2100g.cm |
| Typical Application: | Automotive Parts, Home Application, Medical Apparatus, Industry Apparatus, Business Equipment, Personal Care,etc. | ||
+ Outline Dimension
+ Technical Data For Reference
| MODEL | VOLTAGE | NO LOAD | AT MAXIMUM EFFICIENCY | STALL | ||||||||
| OPERATING RANGE | NOMINAL | SPEED | CURRENT | SPEED | CURRENT | TORQUE | OUTPUT | TORQUE | CURRENT | |||
| V | V | r/min | A | r/min | A | mN.m | g.cm | W | mN.m | g.cm | A | |
| LBL3650-L1 | 8.0-16.0 | 12 | 4304 | 0.28 | 3486 | 1.197 | 20.70 | 211.2 | 7.586 | 109.37 | 1116 | 5.104 |
| LBL3650-L2 | 8.0-26.0 | 18 | 6693 | 0.3 | 5555 | 1.552 | 29.98 | 305.9 | 17.43 | 176.30 | 1799 | 7.537 |
| LBL3650-L3 | 8.0-26.0 | 24 | 8458 | 0.4 | 6851 | 1.794 | 38.73 | 395.2 | 27.77 | 203.84 | 2080 | 7.628 |
Voltage, Torque, Speed, Current, Power and Shaft size can be customized as requirement.
+ Motor Characteristics
+ Applications
- Automotive Parts: Pump, Fan
- Home Application: White Goods, Small Appliance, Fanner, Coffee Machine, Milk Tea Machine
- Medical Apparatus: Medical Pump, Surgery Tools, Medical Stirrer, Centrifugal Machine
- Industry Equipment: Pump, Portable Screwdriver, Small Compressor
- Business Equipment: Printer, Copier, Projector, ATM, Vending Machine
- Personal Care: Hair Dryer, Electric Shaver, Massager
